// THERMAL INSULATION // DCT PIR WHITE

DCT PIR White

Details

DCT PIR White insulation is a premium board for use in residential, industrial and agricultural buildings.

Features

  • Exceptional Strength
  • Proven long term performance
  • High resistance to settlement and compaction
  • Dimensional and edge profile stability
  • Excellent moisture performance
  • Very high resistance to moisture penetration
  • Low vapour permeability
  • High resistance to freeze thaw cycles
  • Durability provides long-term retention of these properties
  • Superior thermal resistance
  • Low thermal conductivity
  • Thinner boards required compared to some traditional materials

Health and Safety

  • Zero ozone depletion potential (ODP)
  • CFC and HCFC Free
  • Global Warming Potential (GWP) <5
  • Green Star Compliance
  • Non-irritant, light and easy to handle
  • Clean, easy cutting, robust and inherent weather resistance
  • Manufactured in accordance with ISO 9001:2000

Applications

  • Car park soffits, concrete roofs
  • Double brick wall, cavity wall, double cavity precast wall, masonry wall external
  • Underside of slab

Technical Data

Product Name:DCT PIR White
PIR insulation board for residential, industrial
and agricultural buildings
Product Description:Rigid polyisocyanurate (PIR) foam core board, faced on both sides with a slightly embossed aluminium foil, white-varnished on the visible side and silver coloured at the back.
Surface finish:50u/m slightly embossed aluminium foil, white-varnished on the visible side and silver coloured at the back.
Product code:DCT PIR White
Colour:White/Silver
Edge treatment:Square edge
Nominal Thickness:20 mm up to 100 mm
Width:1200 mm
Length:2400 mm up to 4000mm
Compressive strength:>150kPa (1.5kg/cm²) CS (10/4) 150
Core volume weight:+30kg/m³
Water absorption by immersion:<1.5% Vol.
Tensile strength perpendicular to surface:>80kPa EN1607
Long-term water absorption:<2%
Fire Classification:AS3837 – AS ISO9705
Dimensional stability DS (TH) 8 according to EN1604. Humidity test 48 hours.Change in length <2%
Change in width <2%
Change in thickness <6%
Standards:The production of these insulation boards is certified according to ISO 9001:2000



Nominal Thickness to R-Value
DCT PIR White
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
200.021870.91
250.021871.14
300.021871.37
400.021871.83
450.021872.06
500.021872.28
600.021872.74
700.021873.20
750.021873.43
800.021873.65
900.021874.11
1000.021874.57

DCT PIR Silver

Details

DCT PIR Silver insulation is a premium board for use in residential, industrial and agricultural buildings.

Features

  • Exceptional Strength
  • Proven long term performance
  • High resistance to settlement and compaction
  • Dimensional and edge profile stability
  • Excellent moisture performance
  • Very high resistance to moisture penetration
  • Low vapour permeability
  • High resistance to freeze thaw cycles
  • Durability provides long term retention of these properties
  • Superior thermal resistance
  • Low thermal conductivity
  • Thinner boards required compared to some traditional materials

Health and Safety

  • Zero ozone depletion potential (ODP)
  • CFC and HCFC Free
  • Global Warming Potential (GWP) <5
  • Green Star Compliance
  • Non-irritant, light and easy to handle
  • Clean, easy cutting, robust and inherent weather resistance
  • Manufactured in accordance with ISO 9001:2000

Applications

  • Car park soffits, concrete roofs
  • Double brick wall, cavity wall, double cavity precast wall, masonry wall external
  • Underside of slab

Specification Clause

DCT PIR polyisocanurate thermal insulation board should be described in the specification as:-

The insulation shall be DCT PIR Silver____mm polyisocanurate (PIR) foam panel with minimum compressive strength 120 kPa. DCT PIR Silver smooth polyisocanurate insulation board is distributed exclusively by DCTech. T: 1800 051 100

Technical Data

Product Name:DCT PIR Silver
PIR insulation board for residential, industrial
and agricultural buildings
Product Description:Rigid polyisocyanurate (PIR) foam core board, faced on both sides with a smooth multi-layer coated aluminium foil.
Product code:DCT PIR Silver
Colour:Silver/Silver
Edge treatment:Square edge
Nominal Thickness:20 mm upto 100 mm
Width:1200 mm
Length:2400 mm
Compressive strength:>120kPa (1.2kg/cm²)CS (10/4) 150
Core volume weight:+30kg/m³
Water absorption by immersion:>80kPa EN1607
Tensile strength perpendicular to surface:>80kPa EN1607
Long-term water absorption:<2%
Dimensional stability DS (TH) 8 according to EN1604. Humidity test 48 hours.Change in length <2%
Change in width <2%
Change in thickness <6%
Standards:The production of these insulation boards is certified according to ISO 9001:2000
Nominal Thickness to R-Value
DCT PIR White
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
200.021870.91
250.021871.14
300.021871.37
400.021871.83
450.021872.06
500.021872.28
600.021872.74
700.021873.20
750.021873.43
800.021873.65
900.021874.11
1000.021874.57

Details

DCT PIR Tissue insulation is a premium board for use in residential, industrial and agricultural buildings.

Features

  • Exceptional Strength
  • Proven long term performance
  • High resistance to settlement and compaction
  • Dimensional and edge profile stability
  • Excellent moisture performance
  • Very high resistance to moisture penetration
  • Low vapour permeability
  • High resistance to freeze thaw cycles
  • Durability provides long term retention of these properties
  • Superior thermal resistance
  • Low thermal conductivity
  • Thinner boards required compared to some traditional materials

Health and Safety

  • Zero ozone depletion potential (ODP)
  • CFC and HCFC Free
  • Global Warming Potential (GWP) <5
  • Green Star Compliance
  • Non-irritant, light and easy to handle
  • Clean, easy cutting, robust and inherent weather resistance
  • Manufactured in accordance with ISO 9001:2000

Applications

  • Car park soffits, concrete roofs
  • Double brick wall, cavity wall, double cavity precast wall, masonry wall external
  • Underside of slab

Specification Clause

DCT PIR Tissue polyisocanurate thermal insulation board should be described in the specification as:-

The insulation shall be DCT PIR Tissue__mm polyisocanurate (PIR) foam panel with minimum compressive strength 150 kPa. DCT PIR Tissue polyisocanurate insulation board is distributed exclusively by DCTech. T: 1800 051 100

Technical Data

Product Name:DCT PIR Tissue
PIR insulation board for residential, industrial and agricultural buildings
Product Description:Rigid polyisocyanurate (PIR) foam core board, faced on both sides with a buff coloured tissue facing
Product code:DCT PIR Tissue
Colour:Buff/Buff
Edge treatment:Square edge
Nominal Thickness:30 mm upto 100 mm
Width:1200 mm
Length:2400 mm
Compressive strength:>120kPa (1.2kg/cm²) CS (10/4) 150
Core volume weight:+30kg/m³
Tensile strength perpendicular to surface:>80kPa EN1607
Long-term water absorption:<2%
Fire Classification:AS3837
Dimensional stability DS (TH) 8 according to EN1604. Humidity test 48 hours.Change in length <2%
Change in width <2%
Change in thickness <6%
Standards:The production of these insulation boards is certified according to ISO 9001:2000
Nominal Thickness to R-Value
DCT PIR Tissue
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
300.0231.3
400.0231.7
500.0232.2
600.0232.6
700.0233.0
800.0233.5
1000.0234.4

Tuff-R

Details

Featuring the highest thermal insulation value of any foam sheathing currently available, Tuff-R™ distributed by DCTech is a closed cell polyisocyanurate (PIR) foam core sandwiched between two durable, aluminium foil exterior facers. The first is a continuous sheet of aluminium foil, the other is aluminium foil-Kraft paper-aluminium foil. Air cannot penetrate the facers, which also minimises water and water vapour intrusion into the polyisocyanurate foam insulation core, and allows the foam R-value to stabilise at a higher value. Tuff-R™ thermal insulation can be easily applied to a variety of substrates.

Tuff-R™ thermal insulation is a rigid board, manufactured with a HFC blowing agent, which has zero ozone depletion potential (ODP) than standard CFC/HCFC blowing agents and is Green Star Compliant.

Applications

  • Car park soffits, concrete roofs
  • Tuff-R is not compliant in exposed applications where AS ISO 9705 determined group classification is required.  Examples are where required by Melbourne Fire Brigade or buildings approved under the NCC 2015.
  • Double brick wall, cavity wall, double cavity precast wall, masonry wall external
  • Underside of slab

Features

  • High R-Value enhances thermal efficiency
  • Facers help reduce are penetration and water vapour intrusion
  • Compatible with most exterior siding treatments
  • Easy to handle, cut and install
  • 15 Year limited thermal warranty

Standards

  • Green Star Compliant
  • CFC and HCFC Free
  • Zero ODP
  • LEED
  • USGBC

Specification Clause
General Application Board

Dow Tuff-R™ PIR general application board should be described in specifications as:–

The insulation shall be Dow Tuff-R™ General application board ____mm thick comprising a premium performance CFC/HCFC–free rigid PIR (Polyisocyanurate) thermoset insulation core with 12.5 micron tri laminate, autohesively bonded foil facings on both sides conforming to fire tests, AS1530–3, manufactured to the highest standards under quality control systems.

Dow Tuff-R™ is distributed by Dynamic Composite Technologies

T: 1800 051 100.

Technical Data

Product Name:Dow Tuff-R™
Polyisocyanurate PIR rigid thermal insulation
Product Description:Dow Tuff-R™ a non structural rigid thermal insulation board consisting of a polyisocyanurate PIR thermoset foam core laminated between smooth, reflective aluminium foil facers on both sides.
Surface finish:Aluminium foil one face and composite foil laminate on the other.
Product code:Tuff-R
Colour:Silver foil facers with foam core
Edge treatment:Square
Nominal Thickness:13 mm
Width:1219 mm
Length:2235 mm
Density:32 kg/m³
Compressive strength:137 kPa (min) @ 10% deformation
Water absorption:0.3%
Blowing agent:HFC
Environmental characteristics:Green Star Compliant, Zero ODP, CFC/HCFC  Free
Nominal Thickness to R-Value
Dow Tuff-R™ PIR @ 23.88°C (75°F) aged for 90 days
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
130.0220.6
200.0220.9
250.0221.15

Thermax Light Duty

Details

Thermax Light Duty™ thermal insulation sheathing  distributed by DCTech is a non structural, rigid board consisting of a glass fibre reinforced Polyisocyanurate(PIR) thermoset foam core laminated between smooth, reflective aluminium foil facers on both sides.

Thermax Light Duty™ has a glassfibre reinforced PIRthermoset foam core, along with chemical modifications, contribute to improved fire performance and dimensional stability. The Thermax Light Duty™ PIR foam core will not melt, flow or drip when exposed to fire, instead it will form a strong char that prevents flame spread and further degradation to the core, unlike EPS (Expanded Polystyrene) which will spread the flame due to oxygen being held between the cells within the panel. The EPS cells are also a thermoplastic, which tend to melt and shrink under intense heat.

Thermax Light Duty™ PIR thermal insulation has bonded aluminium foil facers which serve as effective moisture vapour retarders. Thermax Light Duty™ PIR thermal insulation can be installed exposed to the interior without a thermal barrier which offers a high insulating value.

Applications

  • Thermax Light Duty™ PIR is designed as a thermal insulation and interior finish system for walls and ceilings in metal, wood post frame, and concrete or masonry buildings

Features

  • Durable white acrylic-coated aluminum on one side, embossed aluminium on the other for light-impact areas
  • It can be pressured-washed up to 6,894.7 kPa with a 15-degree or greater spray tip

Standards

  • Thermax Light Duty™ PIR thermal insulation is manufactured with a zero ozone depleting potential. The use of Thermax Light Duty PIR thermal insulation helps reduce the carbon footprint of commercial buildings.

Specification clause – Soffit

Dow Thermax Light Duty Soffit Board should be described in specifications as:–

The soffit insulation supplied by Dynamic Composite Technologies shall be modified PIR (Polyisocynurate) Dow Thermax Light Duty Soffit Board ___mm thick CFC/HCFC–free, rigid modified PIR thermoset insulation core with autohesively bonded 35 μ embossed pure foil facings on both sides, conforming to AS fire tests, AS1530–3, AS3837 Group Classification 1, AS ISO 9705: 2003 Group 1 ceiling only, Group 2 walls and ceilings, FM 4880, manufactured to the highest standards under quality
control systems approved to ASTM C1289-02 by Dow Building Solutions and shall be applied in accordance with the instructions issued by them.

Technical data

Product Name:Dow Thermax Light Duty™
Polyisocyanurate PIR rigid thermoset thermal insulation
Product Description:Dow Thermax Light Duty™ polyisocyanurate PIR rigid thermoset thermal insulation for an interior finish system for walls and ceilings in metal, wood post frames and concrete or masonry buildings.
Surface Finish:31.75 u/m embossed white acrylic-coated aluminum on one side and 31.75 u/m embossed aluminum on the other.
Product code:Thermax LD
Colour:White
Edge Treatment:Square Edge
Nominal Thickness (mm):13, 19, 25, 32, 38, 45, 51, 57, 64, 70, 76
Width:1219 mm
Length:2235 mm
Compressive Strength:172 kPa
Flexural Strength:379.21 kPa
Water Absorption:0.05%
Water Vapour Permanence:<0.03
Maximum use temperature:121°C
Light reflective, visual light spectrophotometer:65%



Nominal Thickness to R-Value
Thermax Light Duty™ PIR @ 23.88°C (75°F) aged for 90 days
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
130.0220.6
190.0220.9
250.0221.2
320.0221.5
380.0221.7
450.0222.0
510.0222.3
570.0222.6
640.0222.9
700.0223.2
760.0223.5

Thermax Heavy Duty

Details

Thermax Heavy Duty™ thermal insulation distributed by DCTech has a glass-fibre reinforced polyisocyanurate (PIR) thermoset foam core faced with 4.0 mil embossed white acrylic-coated aluminium on one side and 1.25 mil embossed aluminum on the other side. The surfaces makes it a durable choice for use in moderate-impact areas.

Thermax Heavy Duty™ PIR thermal insulation can be installed exposed to the interior without a thermal barrier and can be pressure washed up to 2,000 psi with a 15-degree or greater spray tip. Thermax Heavy Duty™ PIR rigid sheathing is designed as an thermal insulation and interior finish system for walls in metal, wood post frame and concrete or masonry buildings.

Thermax Heavy Duty™ PIR thermal insulation offers high, long-term R-Values. The aluminium facers help prevent water and water vapour intrusion into the PIR insulation foam core, and allow the foam to stabilise at a higher R-Value. Used in conjunction with the appropriate joint closure system for the application, Thermax Heavy Duty™ PIR thermal insulation with its low perm rating helps to reduce moisture condensation within and behind the insulation.

Applications

  • High-impact interior finish system for walls in metal, wood post frame, and concrete or masonry buildings

Features

  • Low perm rating helps to reduce moisture condensation within and behind the insulation
  • Thermax Heavy Duty™ PIR thermal insulation can be installed exposed to the interior without a thermal barrier
  • High, long term retained R-Values

Specification Clause – Soffit

Dow Thermax Heavy Duty™ Soffit Board should be described in Specifications as:–

The soffit insulation supplied by Dynamic Composite Technologies shall be modified PIR (Polyisocynurate) Dow Thermax Heavy Duty™ Soffit Board ____mm thick CFC/HCFC–free, rigid modified PIR thermoset insulation core with autohesively bonded 35 micron embossed pure foil facings on both sides, conforming to AS fire tests, AS1530–3, AS3837 Group Classification 1, ISO 9705 Group 1 (25mm), FM 4880, manufactured to the highest standards under quality control systems approved to ASTM C1289-02 by Dow Insulation Limited and shall be applied in accordance with the instructions issued by them.

Technical data

Product Name:Dow Thermax Heavy Duty™
Polyisocyanurate PIR rigid thermoset thermal insulation
Product Description:Dow Thermax Heavy Duty™ Polyisocyanurate PIR rigid thermoset thermal insulation with a white interior finish for walls  in high-impact areas.
Surface Finish:Embossed white acrylic-coated aluminum sheet laminated
on one side and 0.025mm aluminum on the other
Product code:Thermax HD
Glass-fibre reinforced polyisocyanurate
Colour:yellow foam
Edge Treatment:Square Edge
Nominal Thickness (mm):13, 25, 38, 51, 57 and 64 mm
Width:1219 mm
Length:2235 mm
Compressive Strength:172.3 kPa
Flexural Strength:379.2 kPa
Water Absorption:0.05%
Water Vapour Permanence:<0.03
Maximum use temperature:121 °C
Light reflective, visual light spectrophotometer:65%
Nominal Thickness to R-Value
Dow Thermax Heavy Duty™ @ 23.88°C (75°F) aged for 90 days
Nominal Thickness
mm
Lambda/K Value/Thermal
Conductivity
R Value
130.0220.6
250.0221.2
380.0221.7
510.0222.3
570.0222.6
640.0222.9
