ProctorWrap CW is a Class 4 vapour permeable wall wrap designed for use with timber and steel frame commercial wall constructions. ProctorWrap CW-IT is supplied with double integrated tape.

Wall wrap shall be [ProctorWrap CW /ProctorWrap CW-IT (with integrated tape)] vapour permeable sarking membrane, compliant to AS/NZS 4200.1:2017, secured directly to the outside of the wall frame in accordance with the product user guide. AS/NZS 4200.1:2017 Classifications: Light Wall Duty; Water Barrier; Class 4 Vapour Permeable; AS1530.2 Flammability Index ≤ 5; Thickness ≤ 1.0mm; Air barrier; Nonconductive;
Non-reflective; Vapour Permeance to ASTM E96(B) no less than 2.5μg/N.s. “Breather” perforated foil does not comply with this specification.

DCT VulcanWool is a non-combustible high density mineral rock fibre stonewool insulation for use internally or as an external grade insulation with water shedding characteristics, designed for use in ventilated rainscreen facades and other thermal and acoustic wall, roof, floor and ceiling applications in residential and commercial buildings.

The insulation shall be DCT VulcanWool thickness [… mm] & density [… kg/m3] non-combustible (AS 1530.1) with a low (<1kg/m2) moisture absorption (EN 1609.) DCT VulcanWool Stonewool is manufactured under licence for DCTech.

DCT PIR Silver insulation is a general application thermoset PIR insulation board with two low emissivity foil facings, suited for use in non-exposed floor, roof, wall and ceiling applications in residential and commercial buildings.

The insulation shall be DCT PIR Silver […mm] polyisocyanurate (PIR) foam panel with minimum compressive strength of 120 kPa. DCT PIR Silver polyisocyanurate insulation board is manufactured under licence for DCTech.
