Nvelope NVF2F

Details

NVF2F is the Nvelope back frame for vertical floor to floor cladding applications, where intermediate support structure is not available. Making it ideal for re-clad and car park applications.

NVELOPE floor to floor (mullion) box ‘T’ profiles are fixed using NVELOPE support brackets. NVF2F brackets absorb vertical dead loads and wind loading, whilst allowing for thermal expansion and deflection between floors.

Applications

NVELOPE Bracket spacing is determined by your project specific requirements, including panel dimensions, weight of the cladding material, local wind loads and cladding zone.

NVF2F is suitable for face fixing / rivet fixing a wide range of cladding elements. NVF2F can also support NV3 / 4 / 5 and 8. Suitable cladding elements include:

  • Fibre cement Panels
  • High pressure laminate (HPL)
  • ACM & Solid Aluminium Cladding
  • Metal rainscreen panels
  • Brick Slips
  • Terracotta
  • NV3, 4, 5 & 8

Features

  • Manufactured from extruded aluminium alloys conforming to AS/NZS 1866:1997 (material) and EN 755 production standards
  • Non-Combustible to AS1530.1
  • Suitable in high corrosive environments C4 and C5
  • Thermally broken to meet Section J NCC 2019 thermal bridging requirements
  • Engineered to Australian Standards

Standards

  • AS/NZS 1170.0 Structural design actions Part 0: General principles
  • AS/NZS 1664.1 Aluminium structures Part 1: Limit state design
  • AS/NZS 1866 Aluminium and aluminium alloys – Extruded rod, bar, solid and hollow shapes
  • AS1530.1 Methods for fire tests on building materials, components and structures Combustibility test for materials

Download Documents

Description Range of adjustment min (mm) Range of adjustment max (mm) Stock code
*Floor to floor small bracket 72mm 79 127 01/F2F072
Floor to floor medium bracket 122mm 125 177 01/F2F122
Floor to floor large bracket 172mm 175 227 01/F2F172
Floor to floor extra large bracket 222mm 225 277 01/F2F190
Floor to floor isolator 01/F2FISO
Floor to Floor box rail 3600mm (Transom/Mullion) 02/F2FBR-3600
Floor to Floor box T rail 3600mm (Mullion) 02/F2FBRT-3600
40 x 40mm spigot 200mm F2F 03/F2F4040
End Plate/Transom cleat – horizontal F2F 03/F2FCLEAT
*minimum with primary fixing installed in bracket well = 94mm.
all dims are from heal of bracket + 5mm with isolator installed.
