Vetro LD (Low Density) FRP Laminate

This GRP laminate has been created by adapting the VETROLITE technology to obtain a considerable reduction in weight and increased flatness, even for the smallest thicknesses (from 1.3 mm).

LD (low density) laminates offer a considerable reduction in weight and greater flatness whilst containing the same amount of glass fibre as a conventional GRP laminate. They are available in a wide range of RAL colours or even customised colours.

IN GENERAL, THIS LAMINATE OFFERS:

  • Lightweight structure
  • Good resistance to atmospheric agents
  • Good UV stability
  • Good chemical resistance
  • Good electrical insulation
  • Good scratch resistance
  • Ease of cleaning

RECOMMENDED APPLICATIONS

Laminates with gelcoat

  • Motor homes and caravans: construction of external and internal side wall panels
  • Commercial vehicles: construction of external and internal side wall panels
  • Buses: construction of external and internal side wall panels
  • Refrigerated vehicles: construction of external and internal side wall panels
  • Signage

Laminates without gelcoat

  • Floors for camper vans, caravans, refrigerated vehicles and buses.

MAIN CHARACTERISTICS

  • Glass fibre MAT, available in versions ranging from 300 g/m² to 800 g/m²
  • Glass fibre WOVEN ROVING, available in versions ranging from 300 g/m² to 500 g/m²
  • Available in thicknesses ranging from 1.5 mm to 2.9 mm with gelcoat and from 1.2 mm to 2.6 mm without gelcoat
  • Weight 2.0 – 3.6 kg/m² with gelcoat, 1.7 – 3.3 kg/m² without gelcoat
  • External finish: glossy or matt gelcoat, no gelcoat
  • Rear finish: sanded, mechanically sanded, smooth, rough

SPECIFIC PROPERTIES

  • EPA 8015D free styrene content less than 1% in weight
  • ISO 8302 thermal conductivity: 0.065 W/mK
  • UNI EN 12086:1999 resistance to water vapour: 50,000<µ<90,000
  • Operating temperature from -30°C to 70°C
  • Suitable for contact with food in accordance with Directive 2002/72/CE
  • Water absorption with internal method about 1% in weight

FINISHES

The surfaces of Vetroresina’s laminates may have different finishes, depending on the type of application; the external surface may be glossy, matt and with or without gelcoat, whilst the internal surface may be rough, sanded or smooth. All of the laminates can be produced in various RAL colours or even in customised colours. Here are some examples of the finishes available:
